Stretch film manufacturing machine produces high‑tensile plastic stretch film for industrial goods wrapping and cargo‑securing assignments. This film‑extrusion unit melts raw PE pellets and completes casting, stretching, and winding procedures continuously. Multiple width‑thickness combinations satisfy hand‑wrap and machine‑wrap film output demands for packaging‑manufacturing factories.
Stretch Film Manufacturing Machine Complete Technical Specification Table
| Name | Unit | YG600D | YG1000D | YG1250D | YG600S | YG1000S | YG1000SA |
| Double-side sticky | Single-side sticky | ||||||
| Screw | MM | 45 | 65 | 80 | 45+45 | 65+65 | 80+55 |
| L/D ratio | L/D | 33:1 | 33:1 | 30:1 | 33:1 | 33:1 | 30:1 |
| Motor power of extruder | KW | 7.5 | 22 | 37 | 7.5×2 | 22×2 | 37×2 |
| The effective width of dia | MM | 700 | 1250 | 1250 | 700 | 1250 | 1250 |
| Width of product (option） | MM | 500,600 | 1000 | 1000 | 500,600 | 1000 | 1000 |
| Length of roller | MM | 700 | 1250 | 1250 | 700 | 1250 | 1250 |
| Draw-off power of roller | KW | 0.75 | 4 | 8 | 2.2 | 4 | 8 |
| Winding dia | MM | 100-200 | 100-200 | 100-200 | 100-200 | 100-200 | 100-200 |
| Dimensions（LxWxH） | MM | 8000*2400*2500 | 9000*5000*2800 | 10000*3000*4000 | 8000*2400*2500 | 10000*5000*2800 | 10000*3000*4000 |
YG‑series stretch film making machine covers small‑medium to large‑scale stretch‑film production capacity. Compact‑footprint models suit newly‑established packaging workshops, and large‑size units support high‑volume continuous‑run production; our machine can install optional automatic thickness‑detecting modules for stable finished‑film quality.
Working Principle Of Stretch Film Making Machine
This extrusion‑production equipment adopts a multi‑stage screw plasticizing structure. LLDPE raw pellets are fed into the heating extruder barrel and melt under controlled temperature. Molten plastic flows through a flat die to form an initial film sheet, and the stretch film manufacturing machine then sends the sheet into casting‑roller groups for rapid cooling and shaping. After cooling, film enters longitudinal stretching units to gain tensile properties. Subsequent winding stations roll finished stretch film onto paper cores, and online thickness monitoring adjusts technical parameters for consistent film specifications. Waste‑edge recycling mechanism reprocesses leftover materials to lower raw‑material consumption for mass‑production lines.
Core Operational Advantages Of Stretch Film Machine Price
- Stable plasticizing performance: Multi‑zone temperature control system guarantees uniform melting of LLDPE raw material for steady film quality.
- Precise thickness control: Optional real‑time thickness‑inspection module reduces thickness deviation of finished plastic film.
- Integrated waste‑edge recycling: Trimmings get re‑fed into production flow, cutting raw‑material waste and overall manufacturing expenditure.
- Flexible product adjustment: Stretch film manufacturing machine supports switching between hand‑wrap film and machine‑wrap film by modifying process parameters.
- Modular expandable design: Accepts automatic core‑changing, auto‑cutting and online‑printing optional assemblies for upgraded production demands.
- User‑friendly operation: PLC touch‑screen human‑machine interface shortens parameter‑adjustment learning cycle for workshop operators.
Packaging‑plant technicians can adjust heating temperature, stretching ratio and winding tension according to target film‑thickness requirements.
Multi‑Domain Application Coverage For Stretch Film Manufacturing Machine
This plastic‑extrusion production line fulfills film‑manufacturing demands across multiple downstream industrial sectors:
- Logistics Packaging Industry: Produce pallet stretch‑wrap film for container‑loading and goods‑securing in warehousing and freight‑transport workflows.
- Packaging‑Material Factory: Manufacture various hand‑use and machine‑use stretch‑film rolls for downstream distributors.
- Food‑Processing Packaging: Supply protective wrapping film for non‑food‑contact outer‑package bundling assignments.
- Building‑Material Industry: Generate stretch‑film products for moisture‑proof wrapping of tiles, profiles, and construction accessories.
- E‑commerce Supply Chain: Manufacture bundling‑wrap materials for commodity‑packaging and parcel‑consolidation operations.
Practical Procurement & Model‑Selection Guidance For Stretch Film Making Machine
End‑users select YG‑series configuration mainly according to required maximum film width and hourly production output. YG‑FM1000 suits startup‑level small‑capacity workshops; YG‑FM1500 stretch film manufacturing machine balances dimension and throughput for general‑purpose stretch‑film plants; YG‑FM2000 targets wide‑film, high‑output large‑scale industrial‑level production.
Confirm factory floor space and three‑phase power capacity before placing purchase orders. Multiple functional modules can be added for special‑specification film demands, and our machine fluctuates with selected optional accessory combinations.
Frequently Asked Technical Questions About Stretch Film Machine Price
Review common technical and configuration‑related questions before ordering plastic‑extrusion production machinery to eliminate pre‑purchase doubts.
A: This line mainly uses LLDPE pellets as raw input material to produce qualified stretch wrapping film for industrial packaging scenarios.
A: Yes. Operators adjust process‑setting parameters on the PLC control panel to switch finished‑film types without major mechanical modification.
A: Available options contain real‑time thickness detector, an automatic core‑changing device, an auto‑cutting assembly, and an online printing unit for diverse production requirements.
A: Main influencing items include maximum film‑width, hourly output capacity, and quantity of selected optional functional modules.
A: Factory supplies pre‑shipment running‑in inspection, complete operation documentation, spare‑parts supply, and remote technical troubleshooting for global dealers and direct end‑users.
Factory Supply & Customer Inquiry Support Of Stretch Film Manufacturing Machine
YG Machinery manufactures full YG‑series stretch‑film‑making production lines alongside diversified plastic‑converting‑industry machinery portfolios. Every complete line passes a full‑function test‑running inspection before seaworthy export‑grade packaging.
Each shipment includes operation manuals and basic fitting components. Our engineering team offers model‑selection consultation and online technical assistance for global dealers and direct end‑users. Bulk‑purchase contracts enjoy priority spare‑part‑delivery privileges. Submit your target film width and expected hourly output volume to obtain a customised factory quotation.
