Excavator orange peel grapple is a hydraulic multi-jaw excavator attachment designed for irregular bulk material loading, sorting, and stacking. Standard digging buckets cannot wrap tangled scrap metal, branches, and broken construction waste; fixed loading machines lack mobility and bring extra rental costs to scattered job sites. This petal-shaped hydraulic grab solves material slipping and low handling efficiency issues for recycling, demolition, and port projects.
YG Machinery launches the YGO04A/YGO06A/YGO08A/YGO06B/YGO08B full series matching 6–25 ton diggers, with optional 4-jaw or 5-jaw configurations.
Unified Complete Technical Parameter Table For Mini Excavator Claw
| Item/Model | Unit | YGO04A | YGO06A | YGO08A | YGO06B | YGO08B |
| No. of Jaw | piece | 4/5 | 4/5 | 4/5 | 4/5 | 4/5 |
| Suitable Excavator | ton | 6-9 | 10-17 | 18-25 | 10-17 | 18-25 |
| Weight | kg | 355/420 | 900/1000 | 1650/1900 | 850/1000 | 1700/1950 |
| Max Open Jaw | mm | 1200 | 1600 | 2050 | 1900 | 2500 |
| Height of Opened Grapple | mm | 1000 | 1500 | 1700 | 1550 | 2000 |
| Working Pressure | bar | 200 | 260 | 320 | 260 | 320 |
| Working Flow | lpm | 50-100 | 60-120 | 200-250 | 60-120 | 200-250 |
| Capacity | m3 | 0.3 | 0.4 | 0.8 | 0.5 | 1 |
Engineering teams undertaking mixed scrap yard and forestry material transport jobs can deploy an excavator orange peel grapple to finish all grabbing work with a single excavator carrier.
Jaw bodies adopt thick wear-resistant alloy steel and full penetration welding craft, with imported hydraulic oil seals to avoid leakage under long continuous shifts.
Complete Working Principle Of Excavator Orange Peel Grapple
This multi-jaw hydraulic grab runs on coordinated cylinder expansion and retraction powered by the excavator’s auxiliary hydraulic circuit. Scrap mill and port bulk handling contractors dealing with irregular cargo can choose a mini excavator with a claw to boost daily handling output by over 80% versus manual sorting.
Operators move the grapple above target materials via the excavator arm, then control hydraulic cylinders to fully open petal jaws; when aligned with bulk scrap or logs, cylinders retract to lock jaws tightly and form an enclosed clamping cavity to prevent material shedding. Built-in hydraulic two-way lock valves keep jaws closed during lifting, while a 360° rotary bearing allows angle adjustment without repositioning the whole machine. After transporting materials to unloading points, cylinders extend to release loads smoothly.
7 Core Functional Advantages Of Mini Excavator With Claw
- Enclosed Multi-Jaw Clamping Design: 4/5 interchangeable jaw options; tight wrapping reduces loose material spillage during lifting and transit.
- Full 360-Degree Hydraulic Rotation: Freely adjust grabbing angles without excavator relocation, suitable for narrow yard and dock spaces.
- Heavy-Duty Wear-Resistant Structure: Reinforced jaw tips and thickened main frame resist impact from scrap steel and hard rock debris.
- Fully Customizable Configurations: Adjust jaw quantity, opening range, and wear-resistant lining per special material handling demands. Small and medium scrap yard subcontractors with frequent site transfers can invest in an excavator orange peel grapple to cut multi-attachment purchase costs and accelerate project turnover.
- Wide Excavator Compatibility: Universal quick hitch fits 6–25 ton mainstream diggers, no major hydraulic refitting required.
- Stable Hydraulic Safety System: Built-in overload relief valve and bidirectional lock avoid accidental jaw opening under heavy loads.
- Lightweight Optimized Frame: 15% lighter than similar grabs, lowering excavator fuel consumption during long shifts.
Global Full-Scene Application Fields Of Excavator Orange Peel Grapple
- Scrap Metal Recycling Yards: Sort, stack, and load mixed steel scrap, auto parts, and metal waste.
- Demolition Site Cleanup: Grab and separate broken concrete, brick, and construction debris.
- Forestry Log Handling: Transport logs, branches, and biomass raw materials in lumber yards.
- Port & Dock Cargo Transfer: Mini excavator claw load/unload bulk ore, coal, and irregular loose cargo.
- Municipal Waste Disposal: Transfer landfill solid waste and industrial slag materials.
- Quarry & Stone Yard Management: Stack rough rock blocks and waste stone fragments.
- Factory Raw Material Transport: Move bulk industrial waste and recycled raw materials.
- Small-Scale Construction Works: Clear rubble and pile building aggregates on compact job sites.
Step-By-Step Model Matching Guide For Mini Excavator Claw
- Excavator Tonnage Matching: 6–9 ton mini diggers select YGO04A; 10–17 ton mid-size machines fit YGO06A/YGO06B; 18–25 ton heavy excavators adopt YGO08A/YGO08B.
- Long-Term Operation Frequency: Year-round continuous scrap handling selects a thickened wear jaw upgrade; occasional seasonal jobs use standard configuration to control procurement budget. Medium-sized recycling plant operators balancing equipment budget and throughput efficiency can source a mini excavator with a claw to cover scrap, lumber, and aggregate handling simultaneously.
- Material Shape Judgement: Loose small scrap chooses a 5-jaw setup; large solid logs and steel bundles select a 4-jaw configuration.
- Space Limitation Rules: Narrow indoor yards and compact demolition sites pick compact A series; open port/quarry areas adopt wide-opening B series.
Frequently Asked Questions About Mini Excavator With Claw
A1: Standard universal connecting bracket matches mainstream digger models; custom mounting lugs available for special excavator brands on request.
A2: B-series features wider max jaw opening and larger volume capacity, designed for oversized bulk materials; A-series is compact for narrow-space daily handling.
A3: Custom jaw quantity, opening width, and wear-resistant liner solutions are supported for unique handling demands. Factory procurement teams comparing bulk handling attachments can inquire about customized grapple schemes and factory-direct pricing for the excavator orange peel grapple by contacting overseas sales engineers.
A4: Connect to the machine’s standard auxiliary hydraulic pipeline directly; no refitting work required before commissioning.
A5: Regularly lubricate hinge pins, inspect jaw tip wear daily, and avoid long-term overload grabbing operations.
Factory Supply & Global After-Sales Support Of Excavator Orange Peel Grapple
YG Machinery integrates independent R&D, mass production, and global export of excavator hydraulic attachments. Besides multi-jaw orange peel grabs, we supply pile drivers, rock splitters, and hydroseeders for one-stop contractor procurement.
If you need overseas scrap yard project case videos or tailored handling budget quotations, submit your excavator tonnage and main material types to our sales team. You can order a mini excavator claw with factory-direct pricing and a full 12-month machine warranty.
