Mini Digger Quick Hitch | Excavator Quick Attach

Mini digger quick hitch is a hydraulic-mechanical coupling mounted on the excavator dipper arm, used to rapidly swap buckets, breakers, grapples, and other attachments. Traditional pin disassembly relies on sledgehammer manual work, consuming long downtime and bringing pinch risks to workers.

Small-scale landscaping and municipal contractors with frequent tool replacement can rely on mini excavator quick hitch to cut on-site labor costs and raise daily construction output significantly.

YG Machinery launches the full YGMINI-YG100/110 series covering 1.5–45-ton diggers, supplying both hydraulic automatic and mechanical manual versions.

Get A Free Quote

Unified Complete Technical Parameter Table For Excavator Quick Attach

Item/Model	Unit	YGMINI	YG45	YG50/55	YG60/65	YG70/80	YG90	YG100/110
Suitable Excavator	ton	1.5-4	4-7	5-8	9-19	17-23	23-30	33-45
Weight	kg	25	50-60	80	120-130	280-290	420-430	450-580
Length	mm	388	534-545	600	765	924-944	983-1050	1006-1473
Height	mm	246	307	310	388	492	574	558-610
Width	mm	175	258-263	270-280	353-436	449-483	543-568	606-663
Pin-to-Pin Center Distance	mm	80-150	230-270	290-360	380-420	460-480	473-540	550-620
Forearm Open Width	mm	80-140	155-170	180-200	232-315	306-340	375-411	416-469
Retractable Distance of Oil Cylinder	mm	170-206	205-275	340-450	340-486	256-390	413-590	520-590
Top-to-Bottom Pin Distance	mm	159	195	195	220	275	300	360
Pin Diameter	mm	25-40	45-50	50-55	60-70	70-80	80-90	90-120
Working Pressure	bar	32-40	32-40	32-40	32-40	32-40	32-40	32-40
Working Flow	Ipm	10-20	10-20	10-20	10-20	10-20	10-20	10-20

The main frame of the mini digger quick hitch adopts integrated high-strength alloy welding, with triple anti-corrosion coating and a wear-resistant copper bush inside. Civil engineering and demolition teams switching multiple tools daily can deploy it to realize one excavator multi-purpose without extra auxiliary workers.

Inquire For Machine Details

Complete Working Principle Of Mini Digger Quick Hitch

This coupler runs off the excavator auxiliary hydraulics for automatic locking/unlocking. Hydraulic models use in-cab valves to actuate internal lock pins; manual mechanical versions rely on external cranks. All units feature dual hydraulic-mechanical safety latches to hold attachments secure during pressure drops. For tight-site landscaping and farm crews, mini excavator quick hitch slashes tool swap time by over 80% versus manual pin removal.

7 Core Functional Advantages Of Mini Excavator Quick Hitch

Ultra-Fast Tool Swap: Hydraulic model finishes switch within 30–60 seconds; operators stay inside cab without climbing down.
Dual Safety Lock System: Hydraulic pressure lock plus mechanical anti-drop catch eliminate attachment falling risks.
Full Tonnage Compatibility: 7 sizes fit 1.5–45 ton mini to heavy diggers; universal lug design fits mainstream brands.
Customizable Dimensions: Fully customizable pin spacing, opening width, and hydraulic pressure to fit non-standard attachments. Rental firms can adopt a mini digger quick hitch to improve excavator utilization and cut long leasing expenses.
Heavy-Duty Wear Structure: Alloy steel body + replaceable wear bush; service life exceeds 5000 working hours.
Two Optional Types: Hydraulic automatic for high-frequency jobs; mechanical manual for low-budget, occasional use.
Corrosion & Dust Resistant: Multi-layer anti-rust coating fits muddy, waterfront, and open-air construction sites.

Get Latest Price List

Global Full-Scene Application Fields Of Mini Digger Quick Hitch

Municipal Road Maintenance: Pipeline laying, sidewalk demolition, small trench excavation with bucket and breaker switch.
Landscaping Engineering: Pond digging, retaining wall construction, tree transplanting on compact mini diggers.
Agricultural Works: Farm ditch digging, land clearing, small material loading with grapple attachments.
Utility Works: Dig cable trenches, rapidly swap buckets and compactors. Fleet rental & landscape teams adopt an excavator with a quick attach to standardize tool switching on all job sites.
Building Demolition: Indoor dismantling, small concrete breaking with shear and hammer alternation.
Highway & Bridge Construction: Roadbed crushing, slope trimming with multi-type attachments.
Water Conservancy Projects: River dredging, reservoir desilting under humid, muddy conditions.
Mining Auxiliary Jobs: Small ore sorting, rock breaking with compact excavator sets.

Step-By-Step Model Matching Guide For Excavator Quick Attach

Excavator Tonnage Matching: 1.5–4-ton mini machines pick YGMINI; 33–45-ton heavy diggers select YG100/110.
Attachment Compatibility: Custom wide pin sizes suit heavy breakers & grapples. Mid-size rental & landscape businesses use a mini excavator quick hitch for municipal, farm, and demolition tasks.
Operation Environment Rules: For muddy, waterfront sites, select an enhanced anti-corrosion coating configuration; for dry inland yards, use a standard finish.
Working Frequency Judgement: For daily, frequent attachment swap adopts hydraulic automatic type; for seasonal, sporadic jobs, choose the mechanical version to save budget.

Learn More

Frequently Asked Questions About Mini Excavator Quick Hitch

Q1: Can this quick hitch fit all mainstream excavator brands on the market?

A1: Standard lug size matches most brands; customized connecting brackets available for special non-standard diggers.

Q2: What regular maintenance is required to extend hitch service life?

A2: Lubricate all pin bushes daily; inspect locking pin wear and hydraulic oil leakage before each shift. Factory procurement teams comparing excavator coupling accessories can inquire about customized dimension schemes and factory-direct pricing for mini digger quick hitch by contacting overseas sales engineers.

Q3: What’s the core difference between hydraulic and mechanical quick attach?

A3: The hydraulic type is controlled in the cab with high efficiency and a high initial cost; mechanical requires manual pin adjustment with a lower price.

Q4: Besides digging buckets, what attachments can this coupler connect?

A4: Compatible with hydraulic breakers, grapples, shears, compactors, rippers, and all standard excavator tools.

Q5: Does the quick hitch cause overload damage to the excavator hydraulic circuit?

A5: A built-in pressure balance valve stabilizes oil pressure to avoid host hydraulic system overload.

Contact YG Specialists Today

Factory Supply & Global After-Sales Support Of Mini Digger Quick Hitch

YG Machinery integrates independent R&D, mass production, and global export of excavator hydraulic attachments. Besides quick hitches, we supply orange peel grapples, electromagnetic magnets, and pile drivers for one-stop attachment procurement. If you need overseas construction case videos or tailored equipment matching plans, submit your excavator tonnage and main attachment types to our sales team. Global rental and landscaping contractors sourcing fast coupling accessories can order excavator quick attach with factory-direct pricing and a full 12-month machine warranty.
