Portable dry ice cleaning machine pushes granular solid CO₂ via regulated high-pressure air onto contaminated workpiece surfaces. Solid carbon dioxide sublimates rapidly at room temperature, delivering residue-free, high-efficiency industrial cleaning.
YG Machinery designs a full lineup of industrial maintenance solutions after analyzing global factories’ daily cleaning demands. Our equipment inherits mature dry blasting core technology, with stable operating performance and intuitive, adjustable parameters, delivering excellent value for money for manufacturing plants of all sizes.
Full Technical Datasheet For Ice Blast Cleaning Machine
| Parameter Items | YGP7X Technical Indicators | YGA625 Technical Indicators |
| Machine Model | YGP7X | YGA625 |
| Motor Power | 370W | 750W |
| Voltage | AC220V, 50 – 60HZ | AC220V, 50 – 60HZ |
| Air Consumption | 28 – 106 CFM (0.8 – 3.0m³/min), adjustable | 3 – 8m³/min, adjustable |
| Air Supply Pressure | 0.1 – 0.9Mpa | 0.2 – 1.6Mpa |
| Ice Delivery Speed | 0 – 0.75kg/min, adjustable | 0 – 3.6kg/min, adjustable |
| Hopper Capacity | 11kg (23.5 lbs) | 25kg |
| Hopper Size | 0.3m³ | – |
| Degree of Protection | IP54 | IP54 |
| Machine Weight | 55kg | 65kg |
| Dry Ice State | 2.5 – 3mm | 2.5 – 3mm, granular |
| Drive Mode | Direct connection | Permanent magnet synchronous |
| Machine Size | 510x460x910mm | 440x680x780mm |
Both portable dry ice cleaning machines feature IP54 dustproof and waterproof housings to adapt to dusty, humid factory workshops.
Working Principle Of Portable Dry Ice Cleaning Machine
The blasting medium is -78°C solid dry ice pellets. When pellets strike fouling surfaces, intense thermal shock generates micro-brittle cracking, loosening contaminants due to mismatched thermal expansion coefficients between dirt and base substrates.
All pellets fully vaporize after impact without leaving wastewater, chemical residues, or solid waste. For production managers searching for flexible mobile maintenance gear, the dry ice washer series delivers consistent long-term cleaning capacity across diverse workshop environments.
Removable Industrial Contaminants Processed By Portable Dry Ice Cleaning Machine
- Oil, Grease & Carbon Deposits: High-speed dry ice pellets instantly chill grease layers and form separation cracks. Compressed airflow strips engine carbon sludge and heavy mechanical grease with zero chemical additives required.
- Cured Coatings & Mold Carbonized Films: Ultra-low temperature weakens coating adhesion, making aged paint, expired release agents, and mold carbon layers peel off in intact sheets, eliminating abrasion risks caused by manual grinding and polishing. Factories handling multi-material workpieces can adopt an ice blast cleaning machine to unify all surface cleaning procedures within one set of equipment.
- Rust & Oxidation Scale: Dry ice expands roughly 800 times during sublimation inside rust crevices, generating micro-impact force to peel oxidation layers. Low-hardness pellets avoid metal surface damage for damp, long-stored mechanical spare parts.
5 Core Operational Advantages Of Ice Blast Cleaning Machine
- Eco-Friendly Operation With Zero Chemical Residues: Only dry ice pellets serve as the blasting medium. No toxic detergents or industrial wastewater are produced, fully complying with international sustainable manufacturing regulations.
- Non-Abrasive Blasting Safeguards Precision Components. Soft dry ice pellets never scratch, wear, or deform work surfaces; the portable dry ice cleaning machine is safe for high-precision molds and delicate electronic assemblies.
- Fully Dry Operation Mitigates Corrosion & Electrical Short Circuits: No residual moisture remains after blasting, erasing hidden hazards including rust formation, electrical leakage, and long-term equipment corrosion.
- High Throughput Minimizes Production Shutdown Intervals: No cooling or drying waiting period is needed after cleaning. Production lines can restart immediately to mitigate revenue losses caused by prolonged factory halts. Small-scale manufacturers without dedicated maintenance teams can select the dry ice washer to lower recurring equipment upkeep costs year-round.
- Broad Material & Industrial Compatibility: Applicable to metal, plastic, glass, and composite substrates, matching maintenance demands across mold, automotive, electronics, printing, and petrochemical verticals.
Global Industrial Application Scenarios For Portable Dry Ice Cleaning Machine
- Industrial Mold Manufacturing: Clear resin buildup and carbide blockages on tire, injection, and die-cast molds. Molds restart production with no cooling pretreatment.
- Petrochemical Industry: Eliminate reactor coking, heat exchanger resin, and hydrocarbon deposits. No complete equipment disassembly required, preventing pipeline corrosion caused by water washing.
- Printing Industry: Strip cured ink and varnish from gears and guide rails without harming precision bearings, maintaining stable printing performance.
- Automotive Manufacturing: Remove engine carbon deposits, old coatings, and panel grease. The YGA625 unit works with a 16kg air compressor to thoroughly clean valves, combustion chambers, and exhaust passages.
- Electronics & New Energy Precision Manufacturing: Clears PCB solder residue, robot lubricant, and battery compartment adhesive. It enables online cleaning of operating precision equipment with no short-circuit risks. Multi-workshop mass-production factories can deploy units on each production line to standardize daily maintenance.
One-Stop Equipment Supply & Custom Quotation For Dry Ice Washer
YG Machinery specializes in R&D and manufacturing of dry ice blasting equipment, delivering one-stop procurement services for global industrial purchasers. Cooperating with a professional compact dry ice cleaning equipment supplier provides stable technical backing for all daily maintenance tasks.
If you need official quotations or detailed technical datasheets, contact our engineers for customized industrial cleaning schemes. Mid-sized factories with limited maintenance budgets can purchase a portable dry ice cleaning machine to realize low-cost, long-term equipment protection.
